10-100W DVB-T2 ISDB-T ATSC Transmitter

DTT5900-10H 100H tus kws tshaj lij DVB-T / ATSC / ISDB-T digital transmitter, uas muab lub zog tso tawm, nrog 10W / 100W fais fab kev xaiv.

Xa kev nug

Ces

Hauj lwm lawm

DTT5900-10H 100Htus kws tshaj lij DVB-T / ATSC / ISDB-T digital transmitter, uas muab lub zog tso tawm, nrog 10W / 100W fais fab kev xaiv. Nws compact qauv tsim tau zoo heev txuag chaw rau koj chav. Qhov ntau zaus ntawm DTT5900 yog los ntawm 470MHz ~ 806MHz, nws muaj cov kab tawm siab thiab kev ntseeg siab vim nws yuav siv sij hawm siab thiab siab linear LDMOS raj amplifier module. Tsis tas li ntawd, nws txhawb nqa AGC muaj nuj nqi kom muaj zog tso zis.

DIBSYS yeej ib txwm npaj ua kom tau raws li cov neeg siv khoom xav tau los ntawm kev ua kom nws muaj peev xwm tso zis hluav taws xob lossis ntau tus neeg nqa khoom, hloov mus rau cov teeb liab channel thiab kev sib kis dav dav. Peb ua txhua qhov xav tau DVB-T / ATSC / ISDB-T transmitter ntsuas, los ntawm kev kuaj pom thawj zaug rau lub transmitter, mus rau kev ntsuas thaum lub sij hawm commissioning thiab kev tiv thaiv txij nkawm.

Ntsiab nta

Txhim kho cov teeb liab kis tau zoo
Intelligent thiab modularized amplifier chav tsev, siv lub zog nce siab thiab siab linear LDMOS raj amplifier module tsim
Tsawg zog noj thiab super linear tsim los txhim kho lub zog kis tau tus mob, thiab txo cov nonlinear distortion
Txhawb nqa AGC muaj nuj nqi nrog cov khoom siv hluav taws xob txuas ntxiv kom tso cai rau lub tshuab xa hluav taws xob muaj kev ruaj ntseg thiab kev ntseeg tau zoo
LED nyob rau pem hauv ntej vaj huam sib luag txhawb lub tswb thiab teeb liab saib
Stabilized-fais fab mov nrog ntau yam voltage thiab high efficiency
Kev tiv thaiv hluav taws xob ntau, kev tiv thaiv zoo rau tag nrho cov khoom siv.
24-teev ua haujlwm tsis muaj neeg siv, tsim tus phooj ywg zoo
Txhawb kev kuaj tus kheej tsis raug
Txhawb MFN thiab SFN system
Yooj yim rau nruab, elegant tsos

Saib xyuas cov khoom thiab lub tswb xwm txheej

Saib xyuas Cov Khoom	Alarm Status
Fais fab mov	txawv txav
Kub kub	ceeb toom
Amplifier	txawv txav
Kav hlau txais xov pub system	txawv txav

Phase suab nrov

Center zaus sib txawv (Hz)	Local oscillator (dBc/Hz)
@10	Tsawg dua los yog sib npaug rau - 70
@100	Tsawg dua los yog sib npaug rau - 85
@1k	Tsawg dua los yog sib npaug rau - 95
@10 k	Tsawg dua los yog sib npaug rau - 100
@100 k	Tsawg dua los yog sib npaug rau - 111
@1 M	Tsawg dua los yog sib npaug rau - 125

Optical Signal Parameters

Yam khoom	Chav tsev	Technical Specs
Optical wavelength	nm	1100-1600
nominal optical input zog	dBm ib	-1
Input optical zog ntau yam	dBm ib	-15~+2
Max input optical zog	dBm ib	+3
Optical interface		FC/APC
optical reflection poob	dB	³45
